Product Details: Referring to the Audi Flight circuit from Italy, the circuit, parameters, and architecture are exactly the same Simplify the design, shorten the signal circuit, and eliminate all circuits that affect sound quality Subboard design reduces interference between left and right channels Designed with fully discrete components, the sound is balanced, delicate, and extremely pleasant to listen to
CNC machining of all aluminum chassis Oxidation drawing process, non fading
ALPS27 potentiometer, good left and right balance, durable and long-lasting
Panasonic 30W square transformer(If 110V input is required, the transformer needs to be replaced)
Taiwan Teflon oxygen free copper wire signal cable
Taiwan made pure copper high-quality CMC RCA
Twin field-effect transistor input
Specifications: Output effective value: 9.5Vrms
Channel gain: 13.0dB 4.5 times
Signal to noise ratio: 128.8dB
Dynamic range: 129.0dB
Channel crosstalk: -106dB
THD distortion: 0.0033%
THD+N distortion: 0.0037%
Intermodulation distortion: 0.0028%
Frequency response bandwidth: ± 0.046dB 20-20kHz completely flat
Weight: 2.5kg
Size: 250 * 160 * 80mm
Package List: 1 × preamplifier
Without Power Cable
