Product Details:
ARC-SP10 circuit has transparent and clear sound, accurate positioning, and natural high-frequency extension Mid frequency refreshing The low frequency is full and powerful, and the three frequencies are coherent.
1:) 6Z4/6X4 electronic tube rectifier.
2:) 6922/ECC88/E88CC/6D8J * 4 electronic drafts for signal amplification.
3:) Imported Z11 iron core square transformer.
4:) German GAD coupling capacitor.
5:) Equipped with dual VU meters, making music lively and dynamic.
Specifications:
Maximum output: 78.8V
Input sensitivity: -56dB
Frequency response: 5HZ-30KHz
Input impedance: 60K
Output impedance: 600R
Magnification factor: 14.3 times
Size: 430 * 360 * 90mm (excluding protruding parts)
Weight: 10.8kg
Minimum distortion: 0.014% (tested at 1KHz and 1V output)
Minimum input: 1.2mV (1KHz, tested with distortion less than or equal to 1%)
Maximum input: 3.9V/14.2BU
Package List:
1 × ARC-SP10 circuit tube preamplifier
