Specification:
Dimensions: 156 X 150 X 36.5mm
Weight: 713g
Hi-Res Support USB: 768 kHz/32 bit, DSD 512
Inputs: USB-C, Coaxial, Optical, Bluetooth
Outputs: 6.35mm & 4.4mm Headphone output, RCA & 4.4mm Line Output
4.4mm Headphone Output
Output power:
Low gain: 2365mW @ 32 ohms
High gain: 4351mW @ 32 ohms
Frequency response: 20HZ-40KHZ (-0.5dB)
THD + N: 0.02% @ 32 ohms
Dynamic Range: 118DB @ 32 ohms
Channel separation: 111dB @ 32 ohms
Signal to noise ratio: 118DB @ 32 ohms
Output Impedance: <2 Ohm
6.35mm Headphone Output
Output power:
Low gain: 632mW @ 32 ohms
High gain: 1280mW @ 32 ohms
RCA / 4.4mm Line Out
Output power: 2.2V / 4.5V
Frequency response: 20HZ-40KHZ (-0.5dB)
THD + N: 0.02%
Signal to noise ratio: 119DB
